Installation Guide Chapter 4 Install the system 29
UPS 1
Do not plug UPS 1 into
AC power until final
system check
AP2
CPU
Final wiring connections for the wireless Acuity LT System (12 patients)
UPS 2
Do not plug UPS 2 into AC
power until final system
check
H
a
ll
way
Nu
rses station
E
quipment c
lose
t
(C
los
e
t is
op
tiona
l)
MODEM
To analog
phone line
For systems with
4-7 APs, add as
appropriate:
•
UPS
• PoEs, power
adapters,
cords and
cables.
DISPLAY
Connect video to analog HD-15 connector.
PRINTER
(model might vary)
Do not plug the printer into
a UPS. Plug it directly into
an AC outlet.
PoE
PoE
AP1
PoE POWER SUPPLY
SWITCH
Port 1 - AP1
Port 2 - AP2
Ports 3-7 (AP3-AP7)
Port 8 - CPU
SD
ANTENNA
