18 Chapter 4 Install the system Welch Allyn Wireless Acuity LT Central Monitoring System
Table 4. Wireless Acuity LT System equipment
Equipment Item Description a Typical installation location
Display A • Flat panel display
• AC power cord (not shown)
• Data cable for connection to the CPU, HD15-HD15
(not shown)
• External audio cable (not shown; allows adjustment
of display speaker volume)
• A 28-patient system also includes (not shown):
Second flat panel display
AC power cord
Second data cable for connection to CPU (HD15-DVI)
Two video extension cables (to extend the distance
between the CPU and displays)
Desk at nurses station
CPU B
B1
B2 • Sun Microsystems SunBlade 150
• Keyboard (with USB connector)
• Mouse (with USB connector)
OR
Trackball with USB connector for 28-patient system
(not shown)
• AC power cord (not shown)
Desk at nurses station
Printer C • Parallel printer (model may vary from what is shown)
• AC power cord (not shown)
• Parallel printer cable for connection to CPU (not
shown)
Desk at nurses station
Switch D
D1
D2
• 8-port switch (with AC power cord not shown)
• AC power cord (not shown)
• Data cable (for connection to CPU)
• Ground cable (connects to back of switch and to
building ground)
Equipment closet near nurses
station
2 access points
(can be
expanded to
maximum of 7
APs) E
E1
E2
E3
• Symbol Technologies AP-3020/AP-3021
Model can vary
• 2 Sandra “D” (SD) antennas
• 2 whip antennas
• 2 mounting brackets (for mounting APs on wall)
Central hallways near ceiling (on
mounting brackets)
Mounted on ceiling near AP
Attached to AP
Central hallways near ceiling
4 Power-over-
ethernet (PoE)
devices
(additional APs
require
additional PoE
devices, power
adapters, power
cables, power
cords, and data
cables)
F
F1
F2
F3
F4
• 4 spectrum 24 BIAS-T power-over-ethernet (PoE)
devices
(2 PoE devices for each access point)
• 2 PoE power adapters (to provide AC-to-DC power to
2 local PoE devices in equipment room)
• 2 DC power cables (for connection between each AP
and remote PoE)
• 2 AC power cords (for connection to local PoE power
adapters and UPS)
• Ethernet data cables (for connection to PoE adapters,
switch, and APs)
For each AP, one PoE is in the
equipment closet, one PoE is
near the AP
Near PoE devices in equipment
closet
Near APs
Near PoE power adapters in
equipment closet
In equipment closet and near AP
