Installation Guide Chapter 2 Plan the installation 13
Installation worksheet
Use this worksheet to identify locations for Acuity LT System equipment and APs for your
facility. Be sure to consider the following:
• All of the factors regarding obstructions and network coverage ( “Carefully plan
the location of access points” on page 8).
• 60 feet is the approximate maximum distance between an AP and patient
monitor for effective network coverage assuming standard construction. Actual
network coverage varies according to each facility and must be tested on site.
• Two APs must be located between 6 feet and 40 feet from each other. For
systems with more APs, each AP must be within 40 feet of another AP.
• 300 feet is the maximum length of wiring between the switch and the CPU.
• 300 feet is the maximum length of wiring between the switch and the AP.
10 ft.
60 ft.
Approximate maximum distance
between AP and patient monitor
