Selecting waveforms for display
To select waveforms for display, press SETUP, WAVE SEL. Use the NEXT and ON/OFF
buttons to turn on the desired waveforms in the wave select window:
Display priorities
You can turn on more than three waveforms, but only the first three waveforms listed in
the wave select window that are monitored are displayed. The patient parameters being
monitored are listed in the order they will be displayed if all are turned on.
Because of the critical nature of the ECG waveform, you cannot turn off ECG. However, if
ECG is not monitored, another waveform will occupy its place.
The displayed waveforms are also the ones printed if a printer is attached.
Setting the time and date
To set the time and date, from the Main Menu press SETUP, MORE, MORE. The monitor
displays the Time/Day window:
Press NEXT, UP, and DOWN as needed to set the time and date. Then press ENTER to
store the new time and date.
Time/day settings and trends
When you change the hour/minute/second setting for the monitor in the Time/Day
window, the monitor deletes any patient trend data that is older than five hours for non-
NIBP trends or older than eight hours for NIBP trends according to the new clock setting.
However, if the monitor has not yet stored the full capacity of trends and you change the
hour/minute/second setting to a time that is within the stored trend period, previously
stored trends are not erased.
Changing the day, month, or year setting does not affect the stored patient trends.
WAVE SELECT
mmHg
NEXT
PREV MENU
INSERV
ON/OFF
MCO
2
BR
SpO
2
PA
SETUP
ECG : ON RESP : OFF
ART :
ON
SpO2 : ON
PA : OFF NIBP : ON
CO
2
: OFF
35/ 18
( 85)
35 12
92
BATTERY: 9.2 VOLTS
mmHg
NEXT
PREV MENU
DOWN
ENTER
UP
MCO
2
BR
SpO
2
PA
TIME/DAY
TIME DAY
H:MIN:S MO/DA/YR
07:
45
:32 06/12/97
35/ 18
( 85)
35 12
92
WARNING Changing the hour/minute/second setting for the monitor in the
Time/Day window can cause the monitor to erase previously stored patient trend
data.
