Reference Guide
Specifications
107
Nellcor
Characteristic
Specification
a
a.
When performing SpO2 monitoring, the monitor SpO2 channel may not (in rare instances) initially detect a damaged SpO2 sensor or
extension cable (as described in EN865:1997, Section 51.109), but may simply display a flat line and no numerics. If this occurs, try
connecting a new SpO2 sensor (and extension cable, if needed) and restart the monitor to resume normal monitoring.
Saturation (% SpO
2
)
Range
Resolution
Alarm Limits
b
b.
Minimum difference between upper and lower alarm limits is 2%.
0% to 100%
1%
52% to 100% (upper)
50% to 98% (lower)
Probe Accuracy
c
(saturation levels
between 70% and 100%, 28° to 42°C)
Adult/Pediatric
Neonatal
c.
Refer to
Products and Accessories
(810-0409-XX) for accuracy specifications for all Nellcor SpO
2
probes recommended for use.
Digit accuracy: ± 2 counts
Digit accuracy: ± 3 counts
Pulse Rate
Range
Alarm Limits
25 to 250 beats per minute
27 to 250 beats per minute (upper)
25 to 248 beats per minute (lower)
Pulse Rate Accuracy
± 3 beats per minute
Alarm Hold-Off Time Period
10 seconds; resets if the sensor reports levels within limits before 10 seconds
elapses
Circuitry
Microprocessor controlled
Automatic self-test of oximeter when powered on
Automatic setting of default parameters
Automatic alarm messages
Electrosurgery interference
suppression
Yes
Sensor Compatibility
Compatible only with Nellcor sensors listed in Products and Accessories.
Sensor LEDs
RED Wavelength
INFRARED (IR) Wavelength
660 nm (nominal)
890 nm (nominal)
Sensor Energies (Radiant Power)
Electrical Power
Optical Power
52.5 mW max.
15 mW max.
Pulse Rate Accuracy
No Motion
During Motion
± 3 beats per minute
± 5 beats per minute
