KMC Controls KMD–1162 Installation and Operation
2
Specifications
Display LCD, 2-character, 7-segment,
056. in. high.
Compatibility KMD-5800 series controllers
KMD-7000 series controllers
BAC-5800 series BACnet controllers
BAC-7000 series BACnet controllers
Connection
Connector type RJ–12 connects data and power to
compatible controllers
Cable length Maximum 75 feet (22.9 meters)
PC port Four-pin connector for service
connection to software tools
Power 5 volts DC supplied by connected
controller
Mounting Surface mount directly to any flat
surface or to a 2 x 4 inch or 4 x 4 inch
handy-box. Mounting on a 4 x 4 inch
box requires a mounting backplate.
Weight 2.8 ounces (80 grams)
Material Light almond or white plastic
Environmental Limits
Shipping temperature -40 to 140° F (-40 to 60° C)
Humidity 0–95% relative humidity
non-condensing
Accessories
Mounting backplate, 4 x 4 inch
Almond HMO–1161
