EFCO S5500 SSG Captured User Manual
Page 78
EFCO CORPORATION 6/2012
PART NO. Y556
Page 78 of 81
S-5500 SSG and Captured Corner Mullion Installation Instructions
Section XI: Glazed SSG Corners
4-SIDED SSG SILL
(HEAD SIMILAR)
SSG SILL
Caulk joints at the
weather seals must blend
to form a continuous seal
and marry into the
perimeter caulk joint.
SSG VERTICAL
MULLION
GLAZING
INFILL
GLAZING
INFILL
