EFCO S5500 SSG Captured User Manual
Page 24
EFCO CORPORATION 6/2012
PART NO. Y556
Page 24 of 81
S-5500 SSG and Captured Corner Mullion Installation Instructions
Section IV: Alternate Anchorage Method
ANCHOR BOLTS
AS REQ’D.
ANCHOR BOLTS
AS REQ’D.
SHEAR BLOCKS FOR
DROP-ON SILL
SHEAR BLOCKS FOR
DROP-ON HEAD
DEAD LOAD
SHIMS
HEAD ANCHOR
SILL ANCHOR
DROP-ON
SILL
DROP-ON
HEAD
FORMED ALUM.
SHEAR BLOCKS
FORMED ALUM.
SHEAR BLOCKS
CORNER ‘M’
ANCHOR
‘M’ ANCHOR
‘M’ ANCHOR
CORNER ‘M’
ANCHOR
HORIZ. ATTACHMENT
SCREWS
HORIZ. ATTACHMENT
SCREWS
