EFCO S5500 SSG Captured User Manual
Page 76
EFCO CORPORATION 6/2012
PART NO. Y556
Page 76 of 81
S-5500 SSG and Captured Corner Mullion Installation Instructions
Section XI: Glazed SSG Corners
CAPTURED
SILL
VERTICAL SPACER
GLAZING TAPE
Setting blocks
located per shop
drawings.
HORIZONTAL PRESET
GLAZING GASKET
Notch darts on ends
of horizontal gaskets.
SSG VERTICAL
MULLION
Butt horizontal
glazing gaskets into
the vertical spacers.
VERTICAL SSG AND CAPTURED SILL
(HEAD SIMILAR)
Setting blocks
located per shop
drawings.
