EFCO CORPORATION 6/2012 PART NO. Y556 Page 53 of 81
S-5500 SSG and Captured Corner Mullion Installation Instructions
Section VIII: Exterior Cover & Drive-In Gasket
Installation for Captured System
STEP #6 APPLY WEDGE GASKETS
A. Apply the exterior wedge gaskets at the intermediate horizontals. Apply the
gasket to the top of the horizontal first, then to the underside. Refer to “Section X:
Exterior Cover & Drive-In Gasket Installation” beginning on page 49 of the Series
5500 Outside Glazed Installation Instructions for more information.
