EFCO S5500 SSG Captured User Manual
Page 49
EFCO CORPORATION 6/2012
PART NO. Y556
Page 49 of 81
S-5500 SSG and Captured Corner Mullion Installation Instructions
Section VIII: Exterior Cover & Drive-In Gasket
Installation for Captured System
SILL PRESSURE
COVER
CAPTURED
SILL
EXTERIOR WEDGE
GASKETS
HEAD AND SILL HORIZONTAL
Apply a continuous bead
of sealant. (Approx.
1/16” diameter).
SILL CONDITION SHOWN,
HEAD SIMILAR
