1 Optional

duplexer

5 Optional 550-sheet paper feeder

NOTE:

Your multifunction printer

allows for a maximum of three trays
(standard 250-sheet tray, optional
550-sheet paper feeder, and
multipurpose feeder).

2 Operator

panel

6 Multipurpose feeder

3 Front cover 7 Button (right side)

4 Standard

250-sheet
tray

8 Transfer belt unit

9 Automatic Document Feeder (ADF)

NOTE:

When you use the multifunction printer with the multipurpose feeder opened, do not locate the

multifunction printer in direct sunlight. Doing so may cause a malfunction or unnatural screen image.

Leave enough room to open the printer trays, covers, and options. It is also important to allow space around
the multifunction printer for proper ventilation.

Automatic Document Feeder (ADF)
