Brocade Adapters Installation and Reference Manual 185
53-1002144-01
Converged Network Adapters
5
Environmental and power requirements
This section provides environmental and power specifications for the stand-up and mezzanine card
CNAs.
Stand-up CNAs
Table 22 on page 185 lists environmental and power specifications for the stand-up type CNAs.
Beacon flashing
green Beacon flashing
green
3
Beacon flashing
green
3
Port beaconing function.
Beacon flashing
green Beacon flashing
green
4
Beacon flashing
green
4
End-to-end beaconing function. CNA port and port on
connected switch beacon.
Flashing
amber
5
Off Off Unsupported SFP.
1. 1 second on / 1 second off
2. 50 msec on / 50 msec off
3. 1 sec on / 250 msec off
4. 1 sec on / 250 msec off
5. 640 msec on / 640 msec off
TABLE 22 Environmental and power requirements
Property Requirement
Airflow 45 LFM
Altitude Operating - 3,048 meters (10,000 ft.) at 40°C
(104°F)
Nonoperating - 12,192 meters (40,000 ft.) at
25°C (77°F)
Operating Temperature -5°C to 50°C (23°F to 122°F) dry bulb
Operating Humidity 10% to 93%
(relative-noncondensing)
Nonoperating Temperature Minimum: -43°C (-40°F)
Maximum: 73°C (163°F)
Nonoperating Humidity 5% to 95%
(relative-noncondensing)
Power Consumption
CNA and optics 12 W maximum
Operating Voltage Per PCIe 2.0 specifications
TABLE 21 LED operation
Lnk Act Storage State
