Connecting the power swing wiring – Wheatheart X160 Series User Manual
Page 96

3. A
SSEMBLY
W
HEATHEART
- G
RAIN
A
UGERS
X160-85, X160-105, X160-125
96
30875 R0
3.15.4. C
ONNECTING
THE
P
OWER
S
WING
W
IRING
1. Remove cover from the receiver box and top clamp assembly. This means
removing the four sheet metal screws (#14 x 5/8”) located on the sides of the
cover. See Figure 3.50.
2. Remove radio antenna and transmitter from the crate (it will be in a separate
bag). Screw antenna into the socket on the clamp-base.
3. Replace cover, making sure that the antenna fits through the top hole, as
shown in Figure 3.51. Replace sheet metal screws, and tighten securely.
