1. I
NTRODUCTION
W
HEATHEART
- G
RAIN
A
UGERS
X160-85, X160-105, X160-125
10
30875 R0
1.1.2. G
RAIN
H
OPPER
The low-profile grain hopper is designed to be rolled into position to receive grain
for transfer through the boot to the auger discharge spout. Ground clearance can
be adjusted by raising or lowering the position of the hopper wheel axles (see
“Connect the Intake Hopper to the Swing Tube” on page 83).
The grain hopper must be lifted and secured for transport using the hopper lift
arm, hydraulic winch, and transport chain and hook (see Figure 1.4).The hopper
lift arm can be reconfigured for lifting on either side of the auger.
Do not approach, open or close the maintenance hatch located on the transition
between the swing are tube and the hopper unless all power to the auger is
locked out.
DANGER
Rotating Auger Hazard
Contact with rotating flighting will result in
amputation or severe laceration.
DO NOT operate with guards removed or
modified.
Keep hands and feet away from rotating
auger.
Tie up long hair and remove jewellery.
DO NOT wear loose-fitting clothing or items
that could become caught.
Shut off and lock out the power source before
unplugging or cleaning.
