6. Operation
6.1. OPERATOR CONTROLS
The operator controls the following auger actions during operation:
Figure 6.1 shows the hydraulic control valve for the main auger tube hydraulic lift
cylinders.
Figure 6.2 and Figure 6.3 (respectively) show the manual and remote controls for
moving the hopper using the power swing.
For locations for PTO and hydraulic supply controls, please refer to the operating
manual for the attached tractor. For information about extending or retracting the
wheel axles, see “Transport” on page 103 and “Placement” on page 107.
WARNING
Before continuing, ensure you have read and understand the relevant information
in the safety section. Safety information is provided to help prevent serious injury, death, or
property damage.
Table 6.1 Operator Controls
Auger Function
Control type
Location
Lift or lower main auger tube
Hydraulic supply control
valve
Tractor
Open/shut main auger tube
hydraulic flow
Hydraulic shutoff valve
Auger
Move hopper using power swing
Electric switches (manual)
and wireless transmitter
(remote)
Auger
Start/stop augering grain
PTO controls (engage/dis-
engage)
Tractor
Forward/reverse auger rotation
PTO position on speed
reducer
Auger
Grain augering speed
PTO controls (RPM)
Tractor
Raise or lower hopper to or from
transport position
Hydraulic supply control
valve
Tractor
