3. A SSEMBLY W HEATHEART - G RAIN A UGERS
X160-85, X160-105, X160-125
76 30875 R0
3.9. CONNECT HYDRAULIC HOSES AND BALL VALVE
Note:
Elbow fittings are factory installed. Use thread sealant on fitting and hose threads
(not supplied.)
Note:
Use thread sealant (not supplied) on all hydraulic connections.
1. Install Elbow and “T” fittings on the lift cylinders as shown in the appropriate
diagrams for your auger model:
• For X160-85, refer to Figure 3.31 and Figure 3.32
• For X160-105/125, refer to Figure 3.31 and Figure 3.33
Note:
Before attaching short connector hydraulic hoses (labelled 3 and 3A in Figure
3.32 and Figure 3.33) make sure that lift cables are tightly stretched.
2. Install the short hydraulic hoses (3 and 3A in Figure 3.32 and Figure 3.33),
adjusting Elbow and “T” fittings so that the hoses are as far as possible from
the lift cables.
3. Check the short hoses to ensure there is at least a 8-1/2” clearance between
the hoses and the lift cables.
4. Connect the hydraulic pressure hose (labelled 4 in Figure 3.32 and Figure
3.33) to the correct lift cylinder lower “T” fitting for your auger model.
5. Attach the hydraulic fluid return hose (labelled 5 in Figure 3.32 and Figure
3.33) to the correct lift cylinder upper “T” fitting for your auger model.
6. Thread both long hoses through the back arm attach bracket, and route the
hoses as follows:
Table 3.15 Hydraulic Hoses
Part # Hose Description Usage 85 105 125
20757 85 HOSE, 3/8” x 228” Hydraulic Pressure 1
20758 85 HOSE, 3/8” x 396” Hydraulic Return 1
20759 105 HOSE, 3/8” x 302” Hydraulic Pressure 1
20760 105 HOSE, 3/8” x 492” Hydraulic Return 1
20761 125 HOSE, 3/8” x 312” Hydraulic Pressure 1
20762 125 HOSE, 3/8” x 504” Hydraulic Return 1
17468 85 HOSE, 3/8” x 32” Cylinder Connector (rod end) 2
18739 85 HOSE, 3/8” x 17” Cylinder Connector (cap end) 2
20795 105/125 HOSE, 1/2” x 36” Cylinder Connector (cap end) 1 1
20796 105/125 HOSE, 1/2” x 48” Cylinder Connector (rod end) 1 1
28654 1/2” Elbow fittings (pre-installed) --- 4 4
28480 1/2” T fitting --- 2 2
18087 3/8” Elbow fittings (pre-installed) --- 6
18736 3/8” T fitting (MFF) --- 4
WARNING
Wear on hose can cause auger to drop
suddenly, causing serious injury or death and
damage to the equipment.
