W HEATHEART - G RAIN A UGERS 3. A SSEMBLY
X160-85, X160-105, X160-125
30875 R0 69
4. Secure the frame cross braces and the long frame cross brace to the welded
lugs on the lower reach arms with four 1/2” x 1-3/4” bolts, 1/2” flat washers,
and locknuts. Use a fifth 1/2” x 1-1/2” bolt, 1/2” flat washer, and locknut to
fasten the cross-braces together where they cross.
Table 3.13. Lower Frame Parts
Number Description 85’ 105’ 125’ Quantity
1 Lower reach arm, LH 20709 20630 20702 1
2 Lower reach arm, RH 20708 20626 20701 1
3 Axle 20642 20642 20642 1
4 Frame cross braces 20281 20378 20378 2
5 Stabilizer braces 20255 20255 20255 2
6 Short cross member 20646 20646 20646 1
7 Lower tie tube 20726 20640 20726 1
8 5/8” x 2” bolt 19991 19991 19991 2
9 5/8” locknut 19600 19600 19600 2
10 1/2” x 1-1/2” GR8 bolt 19589 19589 19589 8
11 1/2” x 1-3/4” GR8 bolt 19974 19974 19974 5
12 1/2” flat washer 17401 17401 17401 5
13 1/2” locknut 17750 17750 17750 13
14 3/4” x 2” bolt 19592 19592 19592 8
15 3/4” locknut 19601 19601 19601 8
