W HEATHEART - G RAIN A UGERS 3. A SSEMBLY
X160-85, X160-105, X160-125
30875 R0 83
3.11. CONNECT THE INTAKE HOPPER TO THE SWING
TUBE
WARNING
Components are heavy and create a crushing
hazard if improperly handled. Be sure to use
proper hoisting equipment and procedures,
and ensure lifting apparatus is secure.
Lockout the lifting apparatus before working
around or under the raised components.
Failure to do so may cause serious personal
injury.
Table 3.16. Parts Required to Connect the Intake Hopper to the Swing Tube
Number Description Part Number Quantity
1 Transition 10-20766 1
2 Swing tube 10-20587 1
3 5/8” x 1-1/2” bolt 19590 12
4 5/8” locknuts 19600 12
5 1-3/4” flat washers 10-20837 2
6 Bushing support 20589 1
7 Swing flight 10-20592 1
8 3/8” x 1” bolts 29246 2
9 3/8” flat washers 17392 2
10 3/8” locknuts 18956 2
11 Woodruff key 19224 1
12 U-joint 10-29293 1
13 3/8” set screw 19225 2
14 5/16” x 2-3/4” bolt 19965 1
15 5/16” locknut 19980 1
16 Transition flight 20738 1
17 Intake hopper 10-20568 1
18 5/8” x 2” bolts 19991 2
19 5/8” locknuts 19600 2
20 Intake hopper wheels 10-17522 6
21 Axle pins 10-20575 2
22 Hairpins 10-19463 2
