7. M
AINTENANCE
AND
S
TORAGE
W
HEATHEART
- G
RAIN
A
UGERS
X160-85, X160-105, X160-125
130
30875 R0
7.3.5. W
INCH
AND
P
ULLEY
S
ERVICING
• Ensure the cable is slack before servicing the winch.
• Check to make sure cable clamps are secure.
• Keep a film of grease on the gears. Occasionally oil the bushings, drum shaft,
and ratchet.
• Oil cable pulleys as needed.
7.3.6. G
EARBOX
C
OUPLING
S
HAFT
S
ERVICING
1. Remove any accumulated debris with a cloth or a soft wire brush.
2. Inspect the gearbox coupling shaft and U-joints for wear and damage.
Figure 7.4 Gearbox Coupling Shaft U-Joints
