7. M
AINTENANCE
AND
S
TORAGE
W
HEATHEART
- G
RAIN
A
UGERS
X160-85, X160-105, X160-125
134
30875 R0
7.3.14. C
HANGING
G
EARBOX
O
IL
1. Place a pan under the drain plug.
2. Use a wrench and remove the drain plug.
3. Loosen the filler plug so air can enter the gearbox and the oil will drain freely
4. Allow the oil to drain completely.
5. Replace the drain plug.
6. Add oil until the gearbox is half full (center of cross shaft) and replace filler
plug. A flexible funnel may be required. Gearbox should be level when
checking or refilling. Do not overfill.
7.4. STORAGE
To ensure a long, trouble-free life, the following procedure should be followed
when preparing the unit for storage after the season’s use:
1. Fully lower the auger.
2. Remove all residual material from the auger.
3. Remove entangled material from all moving or rotating parts.
4. Wash the entire machine thoroughly using a water hose or pressure washer
to remove all dirt, mud, debris, and residue.
5. Rep air or replace any worn or damaged components to prevent any
unnecessary downtime at the start of the next season.
6. Touch up all paint nicks and scratches to prevent rusting.
7. Position the auger in an area that is dry, level, free of debris, and away from
human activity.
8. Support the hitch on blocks to eliminate prolonged contact with the ground.
9. Lubricate all grease fittings.
10. Clean and lightly lubricate the spline on the PTO driveline. Cover the PTO
driveline with a plastic bag to protect it from the weather and place it in the
transport saddle.
11. Check tire pressure and inflate to 80psi (552 kPa).
12. Chock the wheels.
13. Place the hopper in transport position, ensuring there will be adequate
drainage of any moisture.
WARNING
Before continuing, ensure you have read and understand the relevant information
in the safety section. Safety information is provided to help prevent serious injury, death, or
property damage.
WARNING
To reduce the risk of injury or death, store in
an area away from human activity and do not
permit children to play on or around the stored
machine.
