W HEATHEART - G RAIN A UGERS 6. O PERATION
X160-85, X160-105, X160-125
30875 R0 117
6.2.4. E
LECTRIC
P
OWER
S
WING
O
PERATION
Remotes will be programmed from the factory—to reprogram your remote (or to
add additional remotes, please see the Appendix.
Important:
Registering more than one remote transmitter to a single Power Swing is
acceptable but registering one remote transmitter to multiple Power Swings is
not recommended.
1. On the high end of the Power Swing remote receiver box, flip the power
switch to the ON position (see Figure 6.4).
Figure 6.4 Power Swing Receiver Box
2. For manual operation:
a. Using the direction switch, move the switch in the desired direction of travel
(either F1 or F2).
b. Once finished moving the hopper, release the switch to stop operation (it
should return to the neutral position).
3. For remote operation:
a. Push the green button (no symbol) to turn the remote ON (see Figure 6.3).
b. Push the yellow directional buttons (marked with arrows) located below the
ON/OFF buttons in the direction you want the hopper to move ( Figure
6.3).
c. If this does not work:
i. Push the red button (with an exclamation mark) to turn the remote OFF.
ii. Then push the green button (no symbol) to turn the remote back ON.
iii. Operate the remote as outlined above, using the two yellow directional
buttons (marked with arrows) located at the bottom of the remote to
move the hopper as desired.
