3.7. CONNECT THE AUGER TUBE TO THE FRAME
1. Raise the discharge end of auger (e.g. with a front end loader and a strong
sling or with a chain or block and tackle). The height should be sufficient to
clear the undercarriage assembly.
2. Place undercarriage beneath tube assembly.
3. Connect the lower lift arms to the auger tube:
a. Lift and support the lower attach arms on either side of the auger tube
back-end brackets.
b. Position stabilizer brackets between the back-arm brackets and
corresponding lower reach arms, and secure the lower reach arms and
stabilizer brackets to the back-arm brackets with a tube frame pin, a lower
arm attach bushing, a 7/16” x 3-1/2” GR5 Bolt, and a 7/16” locknut on each
side. Tighten securely.
4. Fasten stabilizer braces to first set of holes (closest to the intake) through the
stabilizer brackets with one 5/8” x 2” bolt and locknut. Place one 5/8” x 2-1/4”
bolt and locknut in the remaining set of holes through the stabilizer braces.
5. Fasten the upper lift arms to the axle: use an axle frame pin, a 1/2” x 1-1/2”
GR8 bolt and a 1/2” locknut, and a 2” flat washer, 7/16” x 3 -1/2” bolt, and
7/16” locknut on each side. Tighten securely.
6. Attach the tubing cross braces between the upper lift arms by loosely
attaching the tubing cross braces using three 1/2” x 1-1/2” GR8 bolts, two
1/2” x 1-3/4” bolts, five 1/2” flat washers, and locknuts.
7. Attach the lift assist bracket to the track shoe as follows:
a. Align the lift assist with the track shoe, and insert the track shoe pin
through the lift assist and the track shoe (see Figure 3.28 for the correct
insertion side).
b. Add the track shoe bushing and then secure the bushing with a 7/16” x
3-1/2” bolt and locknut. Tighten securely.
8. Attach upper lift arms to the lift assist bracket as follows:
a. Raise and support the top of the upper lift arms into position on either side
of the lift assist, aligned with the frame pin holes on the lift assist.
b. Insert the tube frame pin through the top of the upper lift arms and lift
assist.
c. Secure the frame pin in place using a upper lift arm bushing, a
7/16” x 3-1/2” bolt, and a 7/16” locknuts on each side of the frame pin.
Tighten securely.
WARNING
Do not remove tube support until the
assembly in this section has been completed.
