W HEATHEART - G RAIN A UGERS 3. A SSEMBLY
X160-85, X160-105, X160-125
30875 R0 59
9. Rotate the loose “inner” 1” hex nuts on the truss adjust tubes toward the
“outer” nut until they are locked tightly against their respective truss anchor
brackets.
Table 3.11. Truss Towers and Tubes Parts Reference
Fig Ref Part Description Part #
1
Low truss tower
High truss tower
20659
20658
2
1/2” x 1-1/2” bolts
1/2” locknuts
19589
19599
3 Truss anchor brackets n/a
4 1” hex nut 20080
5 Long truss adjust tube 20722
6 Five-bolt tube connect plate 20737
7
1/2” x 1-3/4” bolts
1/2” locknuts
19974
19599
8 Truss tube 20723
9
Seven-bolt tube connect plate (left)
Seven-bolt tube connect plate (right)
20720
20721
10
3/4” x 2-1/2” bolt
3/4” locknut
28446
19601
11 Truss cross brace, long 20725
12 Truss cross brace, short 20778
13
1/2” x 2-1/2” bolt
1/2” locknut
20772
19599
14 Cross-brace clamps 17655
15
7/16” x 1-1/4” Bolt
7/16” locknut
18698
19598
16 3/4” hex nut 19997
