3. A SSEMBLY W HEATHEART - G RAIN A UGERS
X160-85, X160-105, X160-125
72 30875 R0
9. Lower upper end of auger slowly until track shoe rests against upper track
stop and the lift assist stops rest against track.
10. For X160-105/125, attach a short cross-member between the upper lift arms
using eight 1/2” x 1-1/2” bolts and 1/2” locknuts. Tighten securely.
Table 3.14 Parts Required to Connect the Auger Tube to the Frame
Ref # Description 85’ 105’ 125’ Quantity
1 Stabilizer bracket 20625 20625 20625 2
2 Tube frame pin 20682 20682 20682 4
3 7/16” x 3-1/2” GR5 bolt 19547 19547 19547 7
4 7/16” locknut 19598 19598 19598 7
5 Axle frame pin 20681 20681 20681 2
6 1/2” x 1-1/2” GR8 bolt 19589 19589 19589 2
7 1/2”x1-3/4” bolt 19974 19974 19974 10
8 1/2” flat washer 17401 17401 17401 10
9 1/2” locknut 19599 19599 19599 12
10 5/8” x 2” bolts 19991 19991 19991 1
11 5/8” x 2-1/4” bolts 27484 27484 27484 1
12 5/8” locknut 19600 19600 19600 2
13 Upper lift arm 20763
20672 (LH)
20673 (RH)
20704 (LH)
20703 (RH)
2
14 Frame cross braces 20281 20281 20281 2
15 Lift assist 20674 20674 20674 1
16 Track shoe pin 20656 20656 20656 1
17 Upper lift arm bushing 20654 20654 20654 3
18 Lower arm attach bushing 20661 20661 20661 2
19 2” flat washer 20724 20724 20724 2
20 Upper tie tube 20727 20677 20769 1
21 Short cross member n/a 20646 20750 1
22 Back arm bracket n/a n/a n/a 1
