4.2 Instrument and Program Settings ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
40 ￭￭￭￭￭￭￭￭ 873 Biodiesel Rancimat
Displaying the gas flow
Proceed as follows:
1 Open dialog window
￭ Click on the menu item Tools ▶ Gas flow control ▶ Display gas
flow....
The following dialog window appears:
Note
This option is only available if no determination is running.
4.2.5 Recording the temperature
The temperature can be recorded at any time for each individual heating
block.
The program writes the recorded measured values into a text file containing
the following values:
t(s) Time in seconds.
Block [°C] Temperature measured in the heating block.
Ext. Sensor [°C] Temperature measured with the external temper-
ature sensor.
The text file is saved under the name U#X-YYMMDD-hhmmss.txt in the
folder Log, # denoting the instrument number (1...4), X denoting the block
(A or B) and YYMMDD-hhmmss denoting the date and time when the data
logging started.
