74 • Cage and Blade Installation

ClearCube Product Manual and Installation Guide

Figure 33 Fiber Transceiver/BSBP Connection Diagram (BSBP)

Cage

Fiber

Transceiver

Ethernet Cable

Copper C/Port Cables < 10 m

62.5 Micron Fiber

Cable

to Fiber C/Ports
