114 • Appendix A – Specifications
ClearCube Product Manual and Installation Guide
Table 16 Multi-Video Expander Specifications
Video
•
Max. Resolution: 1280x1024
•
Max. Refresh: 75 Hz
•
Digital or Analog output
•
Single, Dual, Triple or Quad display support
Connections
•
Video Output – LFH-60
(optional splitter cable converts LFH-60 to either DVI-I or DB-15)
•
Video Input from C/Port - DB-15
Dimensions
•
MVX —1.3” (h) x 5.1" (d) x 7.7" (w)
•
C/Port to MVX Connector cable length: 6 ft
•
Video splitter cable length: ~1 foot
Power Adapter
•
Universal power adapter included (North America, United Kingdom, Euro &
Japan kits available)
•
Input 100–240 VAC
•
Output 3.8 A, 5 VDC
Environment
•
Stationary office installation, 0– 50° C
•
Under-desk mounting bracket (optional)
•
Regulatory Compliance: FCC/CSA Class A UL1950, IEC950, CE
Mounting
•
The MVX can be located with the C/Port or mounted separately.
Table 17 Fiber C/Port Specifications
Connections
•
2 USB v1.1, PS/2 Keyboard, PS/2 Mouse, Audio In, Audio Out, Video (DB-15)
Fiber Type
•
62.5 micron multi-mode, straight through connection fiber
Connector Type
•
MT-RJ (dual fiber)
Max Video Resolution
•
1280x1024
Max Video Frequency
•
75 Hz
Max. Distance
•
62.5 micron: 500 meters (1640 feet) from BackPack
Environmental
•
Stationary installation, 0-35º C ambient temperature
Signal Loss
•
Total signal attenuation through all patch panels and connectors (excluding
cables) must be
≤ 1 dB.
Power Adapter
•
Input 100–250 VAC 47–63 Hz
•
Output 7 A @ +5 VDC, 1 A @ –5 VDC
