ClearCube Product Manual and Installation Guide
Cage and Blade Installation • 69
1. IP address: 192.168.1.100
2. Gateway: 192.168.1.1
3. Network: 192.168.1.0
4. Netmask: 255.255.255.0
5. Password: clearcube
6. Exit
NOTE: The IP address should be the new one you typed in.
5. Change the Gateway, Network, and Netmask settings, using the same procedure. For
Gateway, use your network’s default gateway setting. For Netmask, use your
network’s subnet mask setting. For Network, use the base network address, which is
typically your subnet mask ANDed with the IP address (also called the Subnet ID). For
example, if your IP address is 192.168.1.154 and your subnet mask is 255.255.255.0,
then if you AND the two addresses together you get a Network setting of 192.168.1.0.
6. Enter
6
to exit. For example:
>6
The result should be:
>6
Save changes and reboot
7. Enter
y
for yes. For example:
>6
Save changes and reboot
The result should be:
Connection to host lost.
The RMC accepts only a lowercase y as a valid positive response. If you type
yes
, or an upper-case
Y
, the changes are not saved. Watch for the
Saving
changes...
message, which confirms the configuration was saved successfully.
NOTE: You may have to close the telnet window by selecting the X in the top right corner.
Connect the CONTROL IN port to your regular network using a standard network cable.
Make sure not to use the cross-over cable you were just using. Test the connection to
the RMC by pinging its address from any other computer on the network.
NOTE: It is recommended that you change your password for security reasons. If you
are unable to connect to the RMC card across your network, make sure the
network connection at the switch for your RMC is able to pass 10Mbps traffic.
Resetting the RMC IP Settings to the Factory Defaults
To reset the IP address on an RMC to the factory default, do the following:
1. Shut down power on all Blades in the primary Cage that houses the RMC.
2. Remove the AC power cord from the back of the primary Cage.
3. Remove the Ethernet cable from the RS485 OUT port on the back of the primary
Cage, if one is connected.
