ClearCube Product Manual and Installation Guide MVX Installation • 95
No tuning features are provided on the MVX. All tuning is accomplished via the C/Port.
Delay tuning (RGB adjustment) on the C/Port may be required for cable runs
exceeding 100 meters.
NOTE: Fiber C/Ports do not require any tuning.
Once the C/Port has been installed and the Blade has been powered up, the user
needs to fine tune the video image by choosing the desired resolution, selecting the
refresh rate that looks best, and using the tuning dial on the rear of the C/Port to
sharpen the video image appropriately. In addition, color tuning may be required using
the RGB color dials on the bottom of the C/Port, as described in the C/Port Installation
chapter.
The equalization knob on the rear of the C/Port affects all the monitors connected to
the MVX equally. Therefore, for the best video performance and consistency,
monitors connected to an individual MVX should be of the same make and model.
Table 5 shows the list of supported configurations for various Blade-C/Port
combinations.
Software Installation and Configuration
The ClearView video driver is based on NVIDIA’s award-winning nView software. It
provides the user with a graphical interface for setting up and configuring the displays.
ClearView is seamlessly integrated within the Microsoft Windows environment,
helping users to maximize productivity through advanced desktop and application
management.
Removing Outdated NVIDIA Drivers
To remove outdated drivers, do the following:
1. Open the Control Panel and double click the System icon.
2. Select the Hardware tab and click the Device Manager button.
3. In the Device Manager window, expand the Display Adapters section,
4. Right-click on the NVIDIA line item matching the video adapter installed on the
Blade and select Properties. Verify that the NVIDIA driver installed on the Blade
Table 13 Blade – C/Port – MVX Support Configuration
Universal C/Port
*
Fiber C/Port
Multi-Video
Solution
(C/Port & MVX)
Single Monitor Blade
(GeForce2 adapter)
Supported Supported
Supported
(Monitor 1 only)
Multi-Video Blade
(Quadro4 adapter)
Supported
(Monitor 1 only)
Supported
(Monitor 1 only)
Supported
*
Only C/Ports that are revision D1 and higher are compatible with the MVX. The label on the
bottom of the C/Port lists its revision as the last characters of the P/N (part number).
