36 • Network Planning and Site Preparation
ClearCube Product Manual and Installation Guide
Japan-Specific Requirements
Model R1200 Blades equipped with 3.4 GHz or greater processors must be installed
into Cages containing rev. H1 or greater BackPacks. BackPacks that are not rev. H1
or greater are rated at only 10 amps, which is insufficient to power eight fully loaded
3.4 GHz processors on a 100 VAC power system. The additional load could blow the
fuse in the BackPack. If you have an existing 10 amp-rated BackPack and have a
requirement to run 3.4 GHz processors on a 100 VAC system, please contact
ClearCube support for assistance.
Table 3 Power and Cooling Requirements – R1200
Units Per Rack
Power Requirements
Typical Current Draw
Thermal
Cages Max No.
Blades
Rack
Space (U)
Peak Power
(kVA)
Peak Current
at 120V (A)
Low Current
at 120V (A)
High Current
at 120V (A)
Generated Heat
Load (Btu/hr.)
Required Cooling
Capacity (tons)
1
8
3
1.2
12
4.5
9
3,685
0.31
2
16
6
2.4
24
9
18
7,370
0.62
3
24
9
3.6
36
13.5
27
11,055
0.93
4
32
12
4.8
48
18
36
14,740
1.24
5
40
15
6
60
22.5
45
18,425
1.55
6
48
18
7.2
72
27
54
22,110
1.86
7
56
21
8.4
84
31.5
63
25,795
2.17
8
64
24
9.6
96
36
72
29,480
2.48
9
72
27
10.8
108
40.5
81
33,165
2.79
10
80
30
12
120
45
90
36,850
3.1
11
88
33
13.2
132
49.5
99
40,535
3.41
12
96
36
14.4
144
54
108
44,220
3.72
13
104
39
15.6
156
58.5
117
47,905
4.03
14
112
42
16.8
168
63
126
51,590
4.34
Table 4 Power and Cooling Requirements – R2100
Units Per Rack
Power Requirements
Typical Current Draw
Thermal
Cages Max No.
Blades *
Rack
Space (U)
Peak Power
(kVA)
Peak Current
at 120V (A)
Low Current
at 120V (A)
High Current
at 120V (A)
Generated Heat
Load (Btu/hr.)
Required Cooling
Capacity (tons)
1
4
3
1.2
10
4.2
8.1
3,315
0.28
2
8
6
2.4
20
8.4
16.2
6,630
0.56
3
12
9
3.6
30
12.6
24.3
9,945
0.84
4
16
12
4.8
40
16.8
32.4
13,260
1.12
5
20
15
6
50
21
40.5
16,575
1.4
6
24
18
7.2
60
25.2
48.6
19,890
1.68
7
28
21
8.4
70
29.4
56.7
23,205
1.96
8
32
24
9.6
80
33.6
64.8
26,520
2.24
9
36
27
10.8
90
37.8
72.9
29,835
2.52
10
40
30
12
100
42
81
33,150
2.8
11
44
33
13.2
110
46.2
89.1
36,465
3.08
12
48
36
14.4
120
50.4
97.2
39,780
3.36
13
52
39
15.6
130
54.6
105.3
43,095
3.64
14
56
42
16.8
140
58.8
113.4
46,410
3.92
* R2100 Blades are double-width, and fit four per Cage.
