ClearCube Product Manual and Installation Guide Cage and Blade Installation • 53
Connectors
Label
Color
Code
Description
CONTROL IN Green
RJ45 connection that receives control and management signals from the previous Cage in
the Control Chain via RS-485. As many as 14 Cages can be connected per Control Chain.
CONTROL OUT Green RJ45 connection that passes control and management signals to the next Cage in the
Control Chain via RS-485.
MANAGEMENT —
RJ45 connection that passes control and management signals from the BackPack to the
Switch Manager console via Ethernet. Has two LEDs in socket to indicate Ethernet link
speed and activity. Connection is self-adapting and does not require a crossover cable.
Switches
MODE Blue
Pushbutton switch that toggles through the blue Mode Selected LEDs on the Connect and
Network Modules. Press this switch to display status for the connections whose blue LED is lit.
FAN MAX —
Pushbutton switch that defeats the temperature sensor in the Fan Pack Module to set fans
to maximum speed.
RST —
Pinhole switch that resets the RMM power. Switching information is not affected. RMM
configuration information is not affected.
DFLT —
Pinhole switch that resets the RMM configuration information to the default configuration
settings, and then resets the RMM power. See Table 11 on page 65 for a list of defaults.
Switching information is not affected.
LEDs
RMM MODE —
Bi-color LED indicates RMM Mode
• Green = Primary
• Yellow = Secondary
• Off = STandby
DHCP —
Bi-color LED indicates IP address assignment mode
• Green = DHCP
• Off = fixed IP address
DC POWER —
Bi-color LED indicates power supply status
• Green = 2 supplies good
• Red = 1 supply bad
• Off = no power or RMM not seated properly
HEALTH —
Bi-color LED indicates system health
• Green = good
• Red = bad
• Off = no power or RMM not seated properly
LINK —
Bi-color LEDs that indicate Ethernet link speed
• Green = 100 Mb/sec.
• Amber = 10 Mb/sec.
ACTIVITY — Green LED – flashing indicates activity
