ClearCube Product Manual and Installation Guide
ClearCube Architecture and Product Overview • 25
Direct Connect BackPack
The Direct Connect BackPack, shown in Figure 6, brings the C/Port connections and
the Ethernet connections directly to the back panel from each individual PC Blade.
Figure 6 Direct Connect BackPack Rear View
