68 • Cage and Blade Installation ClearCube Product Manual and Installation Guide
NOTE: Every primary Cage/BackPack with an RMC installed is shipped with the same
default network settings. If you are using multiple Cage groups, you must
configure new IP addresses per the instructions below to avoid a conflict.
Default RMC Settings: IP Address: 192.168.1.251
Gateway: 192.168.1.1
Network: 192.168.1.0
Netmask: 255.255.255.0
Changing the IP Address of the RMC
To change the IP address on an RMC, do the following:
1. From any computer on the network connected to the RMC, open a telnet session to log
into the RMC using the default RMC IP address of 192.168.1.251. If your network
settings are incompatible with the RMC’s default settings, then you need to select one
computer (notebook, Blade, or other PC) that you can use to program the RMC. Set
this computer’s network settings to be compatible with the RMC default settings and
connect its network port directly to the CONTROL IN port on the Cage using the
provided cross-over cable. To telnet into the RMC from a DOS prompt, type:
H:\>Telnet 192.168.1.251
The result should be:
Password:
2. Type clearcube as the default password. For example:
Password: clearcube
NOTE: You will not see any letters as you type the password. The result should
be:
RMC Configuration
1. IP address: 192.168.1.251
2. Gateway: 192.168.1.1
3. Network: 192.168.1.0
4. Netmask: 255.255.255.0
5. Password: clearcube
6. Exit
3. From the list of options, select 1 to change the IP address. For example:
>1
The result should be:
>1
new ip:
4. Type in the desired new IP address. For example:
>1
new ip: 192.168.1.100 (your desired IP address)
The result should be:
RMC Configuration
