ClearCube Product Manual and Installation Guide ClearCube Architecture and Product Overview • 21
Table 1 Blade LED Functions
LED Color Description
Power
Green Blade is powered on.
Off Blade is powered off.
C/Port
Green C/Port is connected and link is good.
Red C/Port is not connected or link is bad.
Disk
Green Flashing indicates hard drive activity.
Off No hard drive activity.
E-Net
Green
Model R1200: 1000 Mb/s link — flashing indicates activity.
Model R2100: 10/100/1000 Mb/s link — flashing indicates activity.
Yellow/
Amber
Model R1200: 10/100 Mb/s link — flashing indicates activity.
Model R2100: Not applicable.
Off No link.
