ClearCube Product Manual and Installation Guide Cage and Blade Installation • 65
Resetting the RMM Settings to the Factory Defaults
In normal use, the RMM is configured using Switch Manager 4.6. However, it can be
reset to its factory configurations by pressing the DFLT pinhole switch on the back of
the RMM. Table 11 provides the default RMM settings. For information on configuring
an RMM with Switch Manager, see the Switch Manager 4.6 Administrator’s Guide.
Table 11 R4300 RMM Default Configuration Settings
Function Setting Options Default Setting
RMM IP Settings
IP Mode Static | DHCP DHCP
RMM Fixed IP Address Ignored if IP Mode = DHCP 192.168.1.251
RMM Netmask Ignored if IP Mode = DHCP 255.255.255.0
RMM Gateway Ignored if IP Mode = DHCP 192.168.1.1
RMM Location 1 User-editable text string Blank
RMM Ethernet Speed Auto | 10 | 100 Auto
RMM Ethernet Duplex Auto | Half | Full Auto
RMM Location 2 User-editable text string Blank
RMM Auto-Negotiation Settings
RMM Auto-Negotiation Enabled | Disabled Enabled
RMM Status If Auto-Negotiation disabled, Pri | Sec Secondary
Session Time-out Time period for which the session ID is honored 2 minutes
Switch Manager Settings
Switch Manager IP Address xxx.xxx.xxx.xxx 192.168.1.252
SMPort TCP port to the Switch Manager console 8080
Logging
Logging Enabled | Disabled Disabled
Log Server IP Address Only if logging is enabled 192.168.1.253
Log Server Port TCP port to the Log Server 8080
Alerting
Alerting Enabled | Disabled Disable
Alert Server IP Address Only if alerting is enabled 192.168.1.254
Alert Server Port TCP port to the Alert Server 8080
Alert Level • 2 — Errors, Warnings, and Notes
• 1 — Errors and Warnings
• 0 — Errors only
2 (highest)
Security/Encryption Settings
Community String Public | Private Public
SSL Enabled | Disabled Disabled
SSH Enabled | Disabled Disabled
Telnet (un-encrypted) Enabled | Disabled Enabled
HTTP (un-encrypted port 80) Enabled | Disabled Enabled
