ClearCube Product Manual and Installation Guide
Cage and Blade Installation • 41
Cage and Blade Installation
Installation of ClearCube products is straightforward and can be accomplished in just
a few hours. The following instructions are intended for use by IT technicians familiar
with computer systems at the hardware configuration level.
Tools for Installation
All functions and operations described in the following installation procedures can be
performed with the following tools:
•
#2 Phillips screwdriver
•
C/Port adjustment tool (included with Cage accessory kit)
A 1/4” nut driver with a magnetic tip is suggested for removing and replacing the
self-tapping sheet metal screws used on the Cage and BackPack.
Shipment Components
Upon receipt of your shipment, carefully examine the outside of all the boxes before
opening. If you find any external damage, do not open the boxes. Please contact
and notify the shipper that damage has occurred and request an inspection by them
before proceeding.
The following components are shipped in separate cartons:
•
Documentation box– One shipping carton with every order is specially marked
and includes documentation, software CDs (if ordered), a C/Port tuning tool, and
other accessories.
•
Cage – This chassis assembly normally includes the BackPack, and should be
the first carton to be opened and used in the installation process after the racks or
cabinets have been installed.
•
R4300 modules – Packaged separately from the Cage, these modules are
installed by the user when the Cages are installed. Each module box contains the
interconnection cables necessary to interface it to another Cage.
•
PC Blades – These are shipped four to a box. Do not open these boxes until your
Cages are installed and you are ready to install the PC Blades.
•
User ports – C/Port or I/Port desktop units are shipped with or without power
supplies, depending on your configuration. Do not open these boxes until your
Blades are installed and you are ready to begin desktop installations.
