ClearCube Product Manual and Installation Guide Appendix A – Specifications • 113
Appendix A – Specifications
Table 14 BackPack Specifications
Connections
• Hot-swappable modules provide Ethernet, C/Port, and USB connections (R4300)
• 8-slot chassis
• Backwards compatible with Direct Connect or Blade Switching BackPack (R4300)
• Fit 14 Cages (112 PC Blades) in a single 42U rack or cabinet
• Four exhaust fans located in rear (340 CFM total)
• Rear power connection
Audible Noise • < 90dB
Dimensions
• 3U (5.25" high, standard 19" rack width)
• 17.0"(w) x 5.25"(h) x 29.8"(d)
Power Input
• 100–240 VAC, 50/60 Hz, dual redundant PSUs
• Power supplied to each individual PC Blade slot
• 1440 W power required per full Cage (max.)
• 4900 BTU heat generation per hour per full Cage (max.)
• 12 Amps current required per full Cage (at 120 VAC) (max.)
AC Input Fuse
• T15A, 250V (5x20 mm slow-acting 15 amp fuse)
R4300 CAUTION
DOUBLE POLE/NEUTRAL FUSING
Weight
• DCBP/BSBP: 36 lbs (Cage + BackPack), 76 lbs (with 8 PC Blades)
• R4300: 42 lbs (Cage + BackPack), 85 lbs (with 8 PC Blades)
Environment • Rack mounted, 0–35º Celsius (C)
Table 15 C/Port Specifications
Connections
• VGA monitor connection (standard DB-15)
• RJ-45 for PC Blade connection
• Requires full CAT5-type cable with all four pairs connected straight through
• Power connector
• 2 powered USB Ports
• PS/2 Mouse and Keyboard Ports
• Audio Out (34 ohm headset or amplified speaker system required)
• Audio In
Dimensions • 1.3"H x 5.1"D x 7.7"W
Environment • Stationary installation, 0–50º C
Max. Distance
• 200 m (660 ft.) CAT5, CAT5e
• 100 m (330 ft) CAT6
NOTE: For Admin C/Ports, the distance is reduced by half when 9 or more Cages
are attached to a single Admin Daisy Chain.
Power Adapter
• Input 100–240 VAC, 50/60 Hz
• Output 5VDC 3A
