Chapter 12
Configuring Hardware for the MicroVAX
Information Processors
12-8
2. Use the error codes in Table 12.C to trouble-shoot the MicroVAX
Information Processor’s hardware. For more information, see the
VAXstation

3100 and MicroVAX 3100 Maintenance Guide or call
your service representative.
Important: Before you replace any hardware, be sure to check the
cabling and wiring. Also make sure the modules, disk drives, and
program loader are properly connected and powered-up.
Table 12.C
Hardware SelfĆtest Error Codes
If this device: Displays this selfĆtest
error code:
Then:
CLK 0000.0001 the device is good.
0000.0005 set the system time.
<>0000.0001 replace the module.
NVR 0000.0001 the device is good.
0000.0005 set system time after replacing the module battery.
<>0000.0001 replace the module.
DZ 0000.0001 or 0000.4001 the device is good.
<> 0000.0001 or
<>0000.4001
replace the module.
MEM 00XX.0001 (and
X=number of Mbytes
of memory)
the device is good.
<>00XX.0001 replace the module.
MM 0000.0001 the device is good.
<> 0000.0001 replace the module.
FP 0000.0001 the device is good.
<> 0000.0001 replace the module.
IT 0000.0001 the device is good.
<> 0000.0001 replace the module.
