Chapter 11
Checking the Hardware
11-5
If you
have a:
If it is not: It should be: Check the LED
labeled:
RS5 PASS/FAIL GREEN • cycle power by turning off the power from the power supply and then
turning it back on.
• make sure the module is seated properly Ċ see appendix A.
CH 1 • GREEN (if configured
and connected)
• make sure the connection is secure.
• make sure there are no duplicate or overlapping rack
numbers assigned.
• make sure that the rack is configured for a rack address in the range
defined by the scanner pushwheels.
CH 2 • Flashing GREEN (if
configured but some
adapters faulted or
disconnected)
CH 3 • Flashing RED (if
configured but all
adapters faulted or
disconnected)
CH 4 • OFF (if not configured)
CH 5
ERROR
OFF • note flashing error code.
• cycle power by turning off the power from the power supply and then
turning it back on.
BATT LOW OFF make sure the battery is inserted correctly in the battery holder.
LP PASS/FAIL GREEN • cycle power by turning off the power from the power supply and then
turning it back on.
• make sure the pushwheel number is correct.
• make sure the module is seated properly Ċ see appendix A.
MEM ERR 1 OFF make sure the memory module is connected properly Ċ see appendix A.
BATT LOW OFF make sure the battery is inserted correctly in the battery holder.
CVIM
module
PASS/FAIL GREEN • make sure the module is seated properly Ċ see appendix A.
make sure you turn on the power to the power supply module
TRIGGER 1 OFF
• make sure you turn on the power to the power supply.
TRIGGER 2 OFF
MEMORY OFF
MicroVAX
Information
Processor
module EP
PASS/FAIL GREEN • cycle power by turning off the power from the power supply and then
turning it back on.
• make sure the module is seated properly Ċ see appendix A.
module EP
or EE
ENET Flashing GREEN (If
connected and
communicating on the
Ethernet network)
make sure the connection to the Ethernet network is secure.
PROCESSOR OFF 2
BACKPLANE OFF 2
ERROR OFF • cycle power by turning off the power from the power supply and then
turning it back on.
• make sure the module is seated properly Ċ see appendix A.
• it will blink the error code. Call support services.
BATTERY LOW OFF make sure the battery is inserted correctly in the battery holder.
