Chapter 10
10-1
Connecting ac Power
This chapter shows you how to make ac connections to the components.
If you have the following components in your system, you have to connect
ac power to them.
Component: Cat. no.:
power supply 5120ĆP1/B
industrial disk 5730ĆID3, 5710ĆID4, ĆID5, ĆID6, ĆID7
fan chassis 5110ĆFAN8
I/O power supply 1771ĆP2,ĆP4,ĆP7
program loader 5710ĆPL/B
You may also be wiring an:
isolation transformer
master control relay
ATTENTION: Avoid ground loops. Make sure all
grounds are at the same potential. Otherwise you could
damage the equipment.
The following sections show you how to connect ac power to the
above components.
Gather ac Wiring Documentation
Gather the ac wiring documentation to determine which components you
have to connect to ac power.
Chapter Objectives
What You Will Be Doing
