Table 46 - 2090-XXNFMF-Sxx and 2090-CFBMxDF-CDAFxx Feedback Cable
Wire Feedback and I/O
Connectors Wire your feedback and I/O cables.
Connect Premolded Motor Feedback Cables
Motor feedback cables (with premolded connectors) plug directly into 15-pin
motor feedback (MF) connectors on Kinetix 7000 drive (no wiring is necessary).
Motor Circular DIN
Connector Pin RDB-Bxxxxx-3/7 Motors 2090-K7CK-KENDAT
Pin
Signal
1 Sine+ 1
2 Sine- 2
3 Cos+ 3
4 Cos- 4
5 Data+ 9
6 Data- 10
7 CLK+ 7
8 CLK- 8
9 EPWR_5V 5
10 ECOM 6
11 Reserved –
12 Reserved –
13 TS+ 11
14 TS- –
15 Reserved –
16 Reserved –
17 Reserved –
To make this type of connection Go to
Premolded Cable Connect Premolded Motor Feedback Cables below.
Panel-mounted Breakout Board Wire Panel-mounted Breakout Board Kits on page 96 .
Low-profile Connector Wire Low-profile Connectors on page 98 .
IMPORTANT When using Bulletin 2090 cables with premolded connectors, tighten the
mounting screws (finger tight) to improve system performance.
