Chapter 4 Connect the Kinetix 7000 Drive System
Flying-lead Feedback Cable Pinouts
Table 44 - 2090-XXxFMP-Sxx Feedback Cable
(1)
(1) The 2090-XXxFMP-Sxx cables are available as standard, non-flex (catalog number 2090-XXNFMP-Sxx) and continuous-flex (catalog
number 2090-XXTFMP-Sxx).
Table 45 - 2090-XXNFMF-Sxx and 2090-CFBMxDF-CDAFxx Feedback Cable
Motor Bayonet
Connector Pin Rotary Motors with High Resolution Feedback:
MPL-B5xxxx-M/Sx2xAA, MPL-B6xxxx-M/Sx2xAA,
MPL-B8xxxx-M/Sx2xAA, and MPL-B9xxxx-M/Sx2xAA
Drive MF
Connector Pin
Signal
A Sine+ 1
B Sine- 2
C Cos+ 3
D Cos- 4
E Data+ 5
F Data- 10
K Reserved –
L Reserved –
N EPWR_9V 7
P ECOM 6
R TS+ 11
S TS- –
T Reserved –
U Reserved –
V Reserved –
Motor
Circular DIN
Connector Pin Motors with High Resolution Feedback:
MPL-B5xxxx-M/Sx7xAA, MPL-B6xxxx-M/Sx7xAA,
MPL-B8xxxx-M/Sx7xAA, MPL-B9xxxx-S/M-M/Sx7xAA,
HPK-Bxxxx-S/M, and HPK-Exxxx-S/M
Drive MF
Connector Pin
Signal
1 Sine+ 1
2 Sine- 2
3 Cos+ 3
4 Cos- 4
5 Data+ 5
6 Data- 10
9 Reserved –
10 Reserved –
11 EPWR_9V 7
12 ECOM 6
13 TS+ 11
14 TS- –
15 Reserved –
16 Reserved –
17 Reserved –
