Rockwell Automation Publication 2099-UM001D-EN-P - December 2012
161
Appendix
B
Interconnect Diagrams
This appendix provides wiring examples and system block diagrams to assist you
in wiring your Kinetix 7000 system components.
Topic
Page
Figure 72
Kinetix 7000 Drive AC Power Wiring
163
Kinetix 7000 Drive AC Powered with a 8720MC-RPS065BM Regenerative Power Supply
8720MC-RPS065BM Regenerative Power Supply to a Single Kinetix 7000 Drive
8720MC-RPS065BM Regenerative Power Supply to Multiple Kinetix 7000 Drives
Dual 8720MC-RPS065Bx Regenerative Power Supplies to a Single Kinetix 7000 Drive
Kinetix 7000 Drive AC Powered with a 8720MC-RPS190BM Regenerative Power Supply
8720MC-RPS190BM Regenerative Power Supply to a Single Kinetix 7000 Drive
8720MC-RPS190BM Regenerative Power Supply to Multiple Kinetix 7000 Drives
Dual 8720MC-RPS190Bx Regenerative Power Supplies to a Single Kinetix 7000 Drive
Motors with High Resolution Feedback (Bayonet Style Connector)
Motors with High Resolution Feedback (Circular DIN Style Connector)
HPK-Series High-power Motor with High Resolution Feedback
Example with RDD-Series (Bulletin RDB-B) Motors
Figure 87
