Module Configuration, Output, and Input Data

Chapter 4

Output on Mask (OutputOnMask.0 through OutputOnMask.15)

This word lets you turn on any output, real or virtual, when the corresponding bit
is set. This mask is logically ORed with the range masks but logically ANDed
with the Output Off Mask Word described on

page 91

Using the Output On Mask, all of the module’s outputs can be turned on directly
by the user control program, like discrete outputs. A bit which is set in the mask
turns on the corresponding real or virtual output.

See

Output Control on page 36

a nd

Output Control Example on page 43

for

more information about output determination.

Output Off Mask (OutputOffMask.0 through OutputOffMask.15)

This word turns OFF any output, real or virtual, when the corresponding bit is
reset. This mask has veto power over all the Range masks and the Output On
Mask described above. It is logically AND’ed with the results of those masks.

See

Output Control on page 36

a nd

Output Control Example on page 43

for

more information about output determination.

Range Enable (RangeEn.0 through RangeEn.15)

When the bit corresponding to the range number is set,
Range[

n].OutputControl is applied whenever the range is active.

Output Array Word 0

Output On Mask

Out
15

Out
14

Out
13

Out
12

Out
11

Out
10

Out
9

Out
8

Out
7

Out
6

Out
5

Out
4

Out
3

Out
2

Out
1

Out
0

TIP

The corresponding Output Off Mask bit must be set to enable this bit.

Output Array Word 1

Output Off Mask
