Rockwell Automation Publication 1769-UM006E-EN-P - July 2013 123
Appendix
A
Specifications
IMPORTANT For specifications for the packaged controllers, refer to the CompactLogix
Packaged Controller Installation Instructions, publication
1769-IN082 .
Table 25 - Technical Specifications - 1769-HSC
Attribute 1769-HSC
Dimensions (H x W x D), approx. 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Height including mounting tabs is 138 mm (5.43 in.)
Shipping weight (with carton), . 309 g (0.681 lb)
Bus current draw, max 425 mA at 5V DC
0 mA at 24V DC
Heat dissipation 6.21 W
The Watts per point, plus the minimum Watts, with all points energized
Isolation voltage 75V (continuous), reinforced Insulation type, channel-to-system
and channel-to-channel
Type tested at 1200V AC for 2 s
All supply power and/or current ratings Input: 30V DC 40 °C (104 °F )
Output: 1 A per channel, 4 A per module, 30V DC 40 °C (104 °F )
Power supply distance rating Module cannot be more than four modules away from a system power supply
Recommended cable Individually shielded, twisted-pair cable (for the type recommended by the encoder or
sensor manufacturer)
Wire size 0.32…2.1 mm
2
(22…14 AWG) solid copper wire or 0.32…1.3 mm
2
(22…16 AWG)
stranded copper wire rated at 90 °C (194 °F ) insulation max
Wiring category 2 - on signal ports
(1)
Vendor ID code 1
Product type code 109
Product code 19
Enclosure type rating None (open-style)
North American temp code T3C
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 .
