Rockwell Automation Publication 1769-UM006E-EN-P - July 2013 119
Diagnostics and Troubleshooting Chapter 5
X493 010 0 1001 0011 BadCtrAssignToRange_3 This error occurs if you try to set Range0To11[3].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X494 010 0 1001 0100 BadCtrAssignToRange_4 This error occurs if you try to set Range0To11[4].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X495 010 0 1001 0101 BadCtrAssignToRange_5 This error occurs if you try to set Range0To11[5].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X496 010 0 1001 0110 BadCtrAssignToRange_6 This error occurs if you try to set Range0To11[6].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X497 010 0 1001 0111 BadCtrAssignToRange_7 This error occurs if you try to set Range0To11[7].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X498 010 0 1001 1000 BadCtrAssignToRange_8 This error occurs if you try to set Range0To11[8].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X499 010 0 1001 1001 BadCtrAssignToRange_9 This error occurs if you try to set Range0To11[9].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X49A 010 0 1001 1010 BadCtrAssignToRange_10 This error occurs if you try to set Range0To11[10].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X49B 010 0 1001 1011 BadCtrAssignToRange_11 This error occurs if you try to set Range0To11[11].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
(1) X represents the “Don’t Care” digit.
Table 23 - Configuration Error Codes (Continued)
Hex
Equivalent
(1)
Module
Error
Code Extended
Error
Information
Code Error Description
Binary Binary
