84 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Chapter 4 Module Configuration, Output, and Input Data
Range High Limit (Range0To11[n].HighLimit) and Range Low Limit
(Range0To11[n].LowLimit)
IMPORTANT The Range High Limit and Range Low Limit words do not apply to the
L23E packaged controller.
Configuration Array Words 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
46 and 47 Range 0 High Limit Range0To11[0].HighLimit
48 and 49 Range 0 Low Limit Range0To11[0].LowLimit
52 and 53 Range 1 High Limit Range0To11[1].HighLimit
54 and 55 Range 1 Low Limit Range0To11[1].LowLimit
58and 59 Range 2 High Limit Range0To11[2].HighLimit
60 and 61 Range 2 Low Limit Range0To11[2].LowLimit
64 and 65 Range 3 High Limit Range0To11[3].HighLimit
66 and 67 Range 3 Low Limit Range0To11[3].LowLimit
70 and 71 Range 4 High Limit Range0To11[4].HighLimit
72 and 73 Range 4 Low Limit Range0To11[4].LowLimit
76 and 77 Range 5 High Limit Range0To11[5].HighLimit
78 and 79 Range 5 Low Limit Range0To11[5].LowLimit
82 and 83 Range 6 High Limit Range0To11[6].HighLimit
84 and 85 Range 6 Low Limit Range0To11[6].LowLimit
88 and 89 Range 7 High Limit Range0To11[7].HighLimit
90 and 91 Range 7 Low Limit Range0To11[7].LowLimit
94 and 95 Range 8 High Limit Range0To11[8].HighLimit
96 and 97 Range 8 Low Limit Range0To11[8].LowLimit
100 and 101 Range 9 High Limit Range0To11[9].HighLimit
102 and 103 Range 9 Low Limit Range0To11[9].LowLimit
106 and 107 Range 10 High Limit Range0To11[10].HighLimit
108 and 109 Range 10 Low Limit Range0To11[10].LowLimit
112 and 113 Range 11 High Limit Range0To11[11].HighLimit
114 and 115 Range 11 Low Limit Range0To11[11].LowLimit
