118 Rockwell Automation Publication 1769-UM006E-EN-P - July 2013
Chapter 5 Diagnostics and Troubleshooting
X462 010 0 0110 0010 BadScalar_2 The Ctr2Scalar value is invalid, that is, less than one when
NumberofCounters = 10 or 11.
X463 010 0 0110 0011 BadScalar_3 The Ctr3Scalar value is invalid, that is, less than one when
NumberofCounters = 11.
X470 010 0 0111 0000 BadScale_0 The Ctr0CyclicRateUpdateTime is invalid, that is, less than one.
X471 010 0 0111 0001 BadScale_1 The Ctr1CyclicRateUpdateTime is invalid, that is, less than one
when NumberofCounters = 01, 10 or 11.
X472 010 0 0111 0010 BadScale_2 The Ctr2CyclicRateUpdateTime is invalid, that is, less than one
when NumberofCounters = 10 or 11.
X473 010 0 0111 0011 BadScale_3 The Ctr3CyclicRateUpdateTime is invalid, that is, less than one
when NumberofCounters = 11.
X480 010 0 1000 0000 BadRangeLimit_0 The Range0To11[0].LowLimit is greater than or equal to the
Range0To11[0].HighLimit.
X481 010 0 1000 0001 BadRangeLimit_1 The Range0To11[1].LowLimit is greater than or equal to the
Range0To11[1].HighLimit.
X482 010 0 1000 0010 BadRangeLimit_2 The Range0To11[2].LowLimit is greater than or equal to the
Range0To11[2].HighLimit.
X483 010 0 1000 0011 BadRangeLimit_3 The Range0To11[3].LowLimit is greater than or equal to the
Range0To11[3].HighLimit.
X484 010 0 1000 0100 BadRangeLimit_4 The Range0To11[4].LowLimit is greater than or equal to the
Range0To11[4].HighLimit.
X485 010 0 1000 0101 BadRangeLimit_5 The Range0To11[5].LowLimit is greater than or equal to the
Range0To11[5].HighLimit.
X486 010 0 1000 0110 BadRangeLimit_6 The Range0To11[6].LowLimit is greater than or equal to the
Range0To11[6].HighLimit.
X487 010 0 1000 0111 BadRangeLimit_7 The Range0To11[7].LowLimit is greater than or equal to the
Range0To11[7].HighLimit.
X488 010 0 1000 1000 BadRangeLimit_8 The Range0To11[8].LowLimit is greater than or equal to the
Range0To11[8].HighLimit.
X489 010 0 1000 1001 BadRangeLimit_9 The Range0To11[9].LowLimit is greater than or equal to the
Range0To11[9].HighLimit.
X48A 010 0 1000 1010 BadRangeLimit_10 The Range0To11[10].LowLimit is greater than or equal to the
Range0To11[10].HighLimit.
X48B 010 0 1000 1011 BadRangeLimit_11 The Range0To11[11].LowLimit is greater than or equal to the
Range0To11[11].HighLimit.
X490 010 0 1001 0000 BadCtrAssignToRange_0 This error occurs if you try to set Range0To11[0].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X491 010 0 1001 0001 BadCtrAssignToRange_1 This error occurs if you try to set Range0To11[1].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
X492 010 0 1001 0010 BadCtrAssignToRange_2 This error occurs if you try to set Range0To11[2].ToThisCounter to
an invalid value (that is, to a counter that is not available due to
the number of counters selected).
Table 23 - Configuration Error Codes (Continued)
Hex
Equivalent
(1)
Module
Error
Code Extended
Error
Information
Code Error Description
Binary Binary
