Rockwell Automation Publication 1734-UM013J-EN-P - July 2014 193
I/O Assemblies Appendix F
Instance
Decimal (hex) Connection
Type Byte High Byte Low Byte
786 (312h)
Safety and
Standard
0, 1 Input 0 Input 0
2, 3 Input 1 Input 1
4, 5 Input 2 Input 2
6, 7 Input 3 Input 3
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
8 Reserved Reserved Reserved Reserved Ch 3 Input
Status
Ch 2 Input
Status
Ch 1 Input
Status
Ch 0 Input
Status
9
Alarms 0
(1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
10
Alarms 1 (1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
11
Alarms 2
(1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
12
Alarms 3
(1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
Instance
Decimal (hex) Connection
Type Byte High Byte Low Byte
802 (322h)
Safety and
Standard
0, 1 Input 0 Input 0
2, 3 Input 1 Input 1
4, 5 Input 2 Input 2
6, 7 Input 3 Input 3
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
8 Ch 3Combined
Alarm Status
Ch 2 Combined
Alarm Status
Ch 1 Combined
Alarm Status
Ch 0 Combined
Alarm Status
Ch 3 Input
Status
Ch 2 Input
Status
Ch 1 Input
Status
Ch 0 Input
Status
9 Fault Reason 0
10 Fault Reason 1
11 Fault Reason 2
12 Fault Reason 3
13
Alarms 0
(1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
14
Alarms 1 (1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
15
Alarms 2
(1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
16
Alarms 3
(1)
Reserved Tachometer
Dual Low
Tachometer
Underfrequency
Tachometer
Overfrequency
Low Alarm
Status
High Alarm
Status
Low Low Alarm
Status
High High Alarm
Status
17 Reserved Reserved Reserved Reserved Reserved Reserved Reserved Input Power
Instance
Decimal (hex) Connection
Type Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
930 (3A2h) Safety and
Standard 0 Ch 3Combined
Alarm Status
Ch 2 Combined
Alarm Status
Ch 1 Combined
Alarm Status
Ch 0 Combined
Alarm Status
Ch 3 Input
Status
Ch 2 Input
Status
Ch 1 Input
Status
Ch 0 Input
Status
Table 24 - 1734-IE4S Input Assemblies (continued)
